Analog To Digital Signal Converter For Resolver / Encoder / SSI / Inductosyn

In many cases, the feedback generated by a motor is not the type of feedback format required for the servo drive. For such cases RECKONIC offers different types of signal converters to convert from analog formats (resolver, inductance) to digital formats (SSI, Quad A/B/Z).

Please continue reading to learn more or contact us to discuss your requirements.

To convert the analog signal output of your resolvers into a digital signal, you need a converter. RECKONIC offers a selection of efficient components designed to output the digital square wave signals commonly found in encoders. In essence, our converters allow you to create digital resolvers that combine the robustness of a resolver with the digital simplicity of an encoder. This is ideal for industrial automation situations where you need to detect the rotational position of your devices but do not want to deal with the required installation of the sensors.

Improving Motion Control

Using the digital signal from an encoder makes it easier to work with the output data to understand the position and speed of your equipment.
Digital signals are also easier to send to other devices without the need for further processing or external analog-to-digital converters.

Application

• Ideal for closed loop positioning systems
• CNC and machine tool applications
• PLC positioning control
• Index/Rotation tables
• Positioning/telescope/telemetry systems
• Transfer Lines
• Factory Automation
• Robot applications
• Nuclear applications

Get the roughness of a resolver and the digital simplicity of an encoder.
Resolvers for incremental encoder output with index, complement and Hall effect with Hall effect simulation for 2,4,6,8,10, 12, 16 and 20 pole motors.

Application

• Ideal for motor commutation
• CNC and machine tool applications
• PLC positioning control
• Index/Rotation tables
• Positioning/telescope/telemetry systems
• Transfer Lines
• Factory Automation
• Robot applications
• Nuclear applications

Get the ruggedness of a resolver with absolute multiturn position. Resolver to 25 bit absolute position with error status bit and SSI interface with position recovery after power failure and loss of resolver signal detection.

Applications

• Ideal for nuclear applications
• CNC and machine tool applications
• PLC positioning control
• Index/Rotation tables
• Positioning/telescope/telemetry systems
• Transfer Lines
• Factory Automation
• Robot applications

Get the precision of an Inductosyn scale and the digital simplicity of an encoder. Inductosyn to high-resolution incremental encoder output with index and supplemented with loss of Inductosyn signal detection for fail-safe operation

Applications

• Ideal for closed loop positioning systems
• Linear and rotating Inductosyn scales
• CNC and machine tool applications
• Index/Rotation tables
• Positioning/telescope/telemetry systems
• Transfer Lines

With VEGA Inductosyn to SSI you get the accuracy of an Inductosyn scale with absolute multiturn position. Inductosyn to 25 bit absolute position, error status bit and SSI interface with position recovery after power failure.

Applications

• Ideal for nuclear applications
• CNC and machine tool applications
• PLC positioning control
• Index/Rotation tables
• Positioning/telescope/telemetry systems
• Transfer Lines
• Factory Automation
• Robot applications

Advanced Features

• Works with linear and rotating Inductosy™ scales
• Farrand, Heidenhain, Mitsubishi and G&L Inductosyn™ Scales
• Active filter for interference immunity
• Gain range from 60:1 to 2400:1
• Works with a single +5 Vdc supply
• Status LEDs for signal high, low and medium
• Easy to use
• Compact design
• Panel mounting or DIN rail mounting option
